2008 MONDIALE BNC 2260 XL
2008 MONDIALE BNC 2260 XL
Location:Belgium
Description
Opportunity to purchase a beautiful teach-in lathe in excellent condition with 3853 cutting hours.
Can be inspected under power upon appointment and available in May 2025
Cutting hours: 3853
Including the following additional equipment:
SMW autoblok Hi-Grip HG-N-400-128-3 (Chuck)
SWM autoblok GGK-4001 012478 (3)
SWM autoblok GGK-4001 012478 (3)
SMW autoblok 080950 (3)
SMW autoblok 080950 (3
Full technical specifications in the attached document.
Specifications
| Manufacturer | MONDIALE |
| Model | BNC 2260 XL |
| Year | 2008 |
| Condition | Used |
| Stock Number | 00019 |
| Cnc control | Fanuc Oi-TC |
| Swing in gap | 790 mm |
| Swing over bed | 550 mm |
| Swing over cross slide | 310 mm |
| Max. turning length (with turret) | 1500 mm |
| Bar capacity | 69 mm |
| Travel X axis | 300 mm |
| Travel Z axis | 1650 mm |
| Number of tool stations in turret | 8 |
| Tool shank | 40 mm |
| Tailstock quill stroke | 150 mm |
| Quill diameter | 80 mm |
| Max work piece weight (with tailstock) | 2000 kg |
| Spindle speed range | 80-3500 rpm (82 mm bore) |
| Machine dimensions (L/W/H) | 3690 / 2225 / 2050 mm |
| Weight | 4400 kg |
| Cutting hours | 3853 |
